The field of articulatory phonetics is a subfield of phonetics that studies articulation and ways that humans produce speech. Articulatory phoneticians explain how humans produce speech sounds via the interaction of different physiological structures. Generally, articulatory phonetics is concerned with the transformation of aerodynamic energy into acoustic energy. Aerodynamic energy refers to the airflow through the vocal tract. Its potential form is air pressure; its kinetic form is the actual dynamic airflow. Acoustic energy is variation in the air pressure that can be represented as sound waves, which are then perceived by the human auditory system as sound.
Sound is produced simply by expelling air from the lungs. However, to vary the sound quality in a way useful for speaking, two speech organs normally move towards each other to contact each other to create an obstruction that shapes the air in a particular fashion. The point of maximum obstruction is called the place of articulation, and the way the obstruction forms and releases is the manner of articulation. For example, when making a p sound, the lips come together tightly, blocking the air momentarily and causing a buildup of air pressure. The lips then release suddenly, causing a burst of sound. The place of articulation of this sound is therefore called bilabial, and the manner is called stop (also known as a plosive).
Palatography[edit]
In order to understand how sounds are made, experimental procedures are often adopted. Palatography is one of the oldest instrumental phonetic techniques used to record data regarding articulators.[7] In traditional, static palatography, a speaker’s palate is coated with a dark powder. The speaker then produces a word, usually with a single consonant. The tongue wipes away some of the powder at the place of articulation. The experimenter can then use a mirror to photograph the entire upper surface of the speaker’s mouth. This photograph, in which the place of articulation can be seen as the area where the powder has been removed, is called a palatogram.[8]
Technology has since made possible electropalatography (or EPG). In order to collect EPG data, the speaker is fitted with a special prosthetic palate, which contains a number of electrodes. The way in which the electrodes are “contacted” by the tongue during speech provides phoneticians with important information, such as how much of the palate is contacted in different speech sounds, or which regions of the palate are contacted, or what the duration of the contact is.
